M22^™

Modular Aesthetic Laser Multi-Application Platform

M22™ is a modular multi-application platform for the treatment of over 30 skin conditions and hair removal.
Used by physicians around the world, M22™ enables you to treat a vast variety of patients and conditions with excellent outcomes.

Contact us

4 Multiple Technologies in One Modular System

Universal IPL

IPL Laser Machine with Optimal Pulse Technology
ResurFX™

The only true fractional non-ablative technology
Multi-Spot™ Nd:YAG

Laser With Multiple Sequential Pulsing Technology
Q-Switched Nd:YAG

For skin toning by treatment of pigmented lesions and dark tattoo removal

IPL Laser Machine with Optimal Pulse Technology

M22™ Universal IPL module enables you to treat a myriad of conditions with a single, versatile handpiece.
The Universal IPL handpiece is designed with 9 ExpertFilters™ tailored to the condition being treated and computer-enabled filter recognition for enhanced safety and ease-of use. With the Universal IPL handpiece change ExpertFilters™ in seconds instead of attaching a whole new handpiece.

The Universal IPL handpiece saves not only treatment time and storage space, but is also extremely cost efficient because there is no need to purchase multiple IPL handpieces. Three SapphireCool™ lightguides, for large and small areas, maximize patient comfort with continuous contact cooling.

IPL With Optimal Pulse Technology (OPT™)

The Optimal Way To Broaden A Patient Base, Comfortably

The Lumenis OPT™ advantages:

Control pulse shape by equalizing energy distribution over the entire pulse or sequential pulses
Gentler, more comfortable, patient-friendly procedures, with lower effective fluences
High peak power, shorter pulses – optimal for IPL skin treatments using photorejuvenation and treatment of benign pigmented lesions
Advanced OPT™ will also allow determining the specific fluence per sub-pulse when using multiple sequential pulsing, for fine-tuned treatment settings

The ResurFX™ module of M22™ is the only true fractional non-ablative technology. One pass is all it takes.

Unlike other fractional technologies, ResurFX™ needs only one pass to be effective, saving you time and protecting the patient’s skin.

ResurFX™ uses a 1565 nm fiber laser and a very advanced scanner, which enables you to choose from more than 600 combinations of shape, size and density for optimal treatment.

ResurFX™ With CoolScan™ For Optimal Treatment

The ResurFX™ module has a state-of-the-art CoolScan™ scanner for non-sequential scanning. The patent pending algorithm places each fractional spot in a controlled manner to protect the tissue from heat accumulation and overheating. This ability is unique to the ResurFX™ 1565nm fiber laser. The ResurFX™ handpiece is equipped with continuous contact cooling, to increase patient comfort during treatment.

Nd:YAG Laser With Multiple Sequential Pulsing Technology

Multiple-Sequential Pulsing

The Nd:YAG module of M22™ offers treatments for telangiectasias, hemangiomas, leg veins and facial wrinkles. Precise and comfortable treatment with 4 cooled and easily changed lightguides. Multiple Sequential Pulsing, which is available in both the Nd:YAG and IPL modules on M22™, enables cooling between a sequence of pulses, to protect the epidermis while allowing the safe use of higher fluences. This enables treatment on all skin types, including darker skin, and reduces the chance of unwanted side effects in vascular lesion treatments.

How it Works:

Light energy is delivered during the pulses, and the tissue cools during the delays. More energy is safely delivered to the target.

What It Does:

Multiple-Sequential Pulsing allows for cooling between pulses to safely remove hair on all skin types including darker skin and reduces the chance of skin damage in vascular lesion treatments.

Q-Switched Nd:YAG

For skin toning by treatment of pigmented lesions and dark tattoo removal.

The ResurFX™ module has a state-of-the-art CoolScan™ scanner for non-sequential scanning. The patent pending algorithm places each fractional spot in a controlled manner to protect the tissue from heat accumulation and overheating. This ability is unique to the ResurFX™ 1565nm fiber laser. The ResurFX™ handpiece is equipped with continuous contact cooling, to increase patient comfort during treatment.

“Top-Hat” Beam Profile Advantages

Enhanced treatment safety and efficacy by homogeneous distribution of energy
Top-hat beam profile minimizes epidermal damage, tissue textural changes and the occurrence of scarring
A lack of an homogenizer might result in hot spots within the beam and increased risk of scarring
